Name: High Environmental Performance Sunlight Readable Panel PC Touchscreen 1000nits Brightness
Brand: Shenzhen ITD Display Equipment Co., Ltd.
SKU: ITD12PPCT1HBPJ1
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Housing Material: Steel Chassis

Color: Black Or Silver

Housing Type: Panel Mount, VESA Mounting

MTBF: 50000Hours

24/7/365 Use: Supported

Brightness: 1000nits

CPU: J1900,I3,I5

Resolution: 1024*768

Highlight:

all in one touch pc

all in one panel pc

Basic Infomation

Place of Origin: China

Brand Name: ITD

Certification: CE, FCC, RoHS

Model Number: ITD12PPCT1HBPJ1

Payment & Shipping Terms

Packaging Details: 1-5pcs/CTN, Safe, Firm

Delivery Time: 15-20 Business Days

Payment Terms: T/T, Western Union, Paypal

Supply Ability: 5000PCS/Month

Gallery

High Environmental Performance Sunlight Readable Panel PC Touchscreen 1000nits Brightness

Product Description

12.1 inch high brightness sunlight readable industrial panel mount touch all in one Panel PC with touchscreen optional

ITD's 12.1" high bright sunlight readable Panel PC's are built with industrial grade components, and integrated with the Intel Celeron Processor J1900. These sunlight readable Panel PC's are perfect for many demanding environments that require a space saving solution capable of 24/7 high performance computing. All of our panel pc bezels are gasket sealed for added NEMA and Ingress Protection

BENEFITES

- 12.1" Very Bright Active Matrix Sunlight Readable TFT Display; 1000 nits (cd/m2)

- High-Luminance Solid-State LED-enhanced Backlighting

- Optical Bonding of Touch Screen Directly to the Front Surface of the LCD Optional

- Intel Celeron 2 GHz Quad Core Processor

- 4GB, Max.8G System Memory

- 500GB HDD or 126GB SSD, Bigger Capacity Optional

- NEMA 4 (IP65) - Black Powder Coat Aluminum Front Bezel

- Resistive Touch Screen Standard (PCAP, IR Touch Optional)

- Energy Efficient, Low Power Consumption

- High Environmental Performance and Reliability

- Wide Operational Temperature Range, -10°C to +60°C

High Brightness Panel Mount Panel PC
Model Name		ITD12PPCG1HB**
IP Rating		IP65 Front Panel
PC Systems Options
ARM Android Based RK3288(RK3368 optional)	X86 Windows Based		X86 Windows Based
CPU: Quad-Core Cortex-A17 1.8GHz	CPU: Intel® Celeron J1900		CPU: Intel Core i3/i5/i7
Chipset: N/A	Chipset: Intel® HD Graphics, Support 1080p		Chipset: Intel® HD Graphics, Support 1080p
Memory: 1G/2G	Memory: 2GB(Max. 8GB)		Memory: 2GB(Max. 8GB)
HDD/SSD: 8G	HDD/SSD:500G/64G		HDD/SSD:500G/64G
1×HDMI	1×VGA, 1×HDMI		1×VGA, 1×HDMI
1×USB 2.0	2×USB 2.0, 2×USB3.0		2×USB 2.0, 2×USB3.0
1×mini-SD slot	1×COM(RS232/422/485)		1×COM(RS232/422/485)
1×LAN	1×LAN		1×LAN
1×Audio Out	1×Audio Out, 1×MIC In		1×Audio Out, 1×MIC In
Expansion: SSD	Expansion: USB, COM, Mini-PCIe		Expansion: USB, COM, Mini-PCIe
LCD Panel
Screen Diagonal (Inch/cm)		12.1”
Display Active Screen Size (mm)		246.0(H)X184.5(V)
Aspect Ratio		4:3
Physical Resolution		800×600(1024×768 optional)
Maximum Resolution Supported		1920X1080
Colors		16.7M
Brightness (cd/m²)		1000(1500 Optional)
Contrast Ratio		500:1
View Angels		80/80/75/75
Backlight/Backlight Lifetime		LED Backlight with 50000 Hours’ Lifetime
Touch Panel
Touch Options		Resistive, IR, PCAP, SAW
Touch Drivers		Windows, Linux, Android, Mac, Raspberry Pi
Operation
Operating Temperature Range		-10~60°C (-20~70°C Optional)
Humidity Range (RH)		10-90%
24/7/365 Use		Supported
Power
Power Indicator		Green LED
Power Input		DC 12V
Power Consumption		35W
Order Information
12.1”1000nits Panel Mount Panel PC with Resistive Touch, J1900		ITD12PPCT1HBJ1
12.1”1000nits Panel Mount Panel PC with PCAP Touch, J1900		ITD12PPCT5HBJ1
12.1”1000nits Panel Mount Panel PC with IR Touch, J1900		ITD12PPCT2HBJ1
12.1”1000nits Panel Mount Panel PC with Tempered Glass, J1900		ITD12PPCG1HBJ1
12.1”1000nits Panel Mount Panel PC with Resistive Touch, i5		ITD12PPCT1HBI5
12.1”1000nits Panel Mount Panel PC with PCAP Touch, i5		ITD12PPCT5HBI5
12.1”1000nits Panel Mount Panel PC with IR Touch, i5		ITD12PPCT2HBI5
12.1”1000nits Panel Mount Panel PC with Tempered Glass, i5		ITD12PPCG1HBI5

APPLICATION
High Environmental Performance Sunlight Readable Panel PC Touchscreen 1000nits Brightness 0

OUR FACTORY
High Environmental Performance Sunlight Readable Panel PC Touchscreen 1000nits Brightness 1
