Name: High Definition 6.5 Inch Sunlight Readable Panel PC 4GB Energy Efficient
Brand: Shenzhen ITD Display Equipment Co., Ltd.
SKU: ITD06PPCT1HBPJ1
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Housing Material: Steel Chassis

Housing Type: Panel Mount, VESA Mounting

Operating Temperature: -10~60℃(-20~70℃ Optional)

Operating Humidity: 10%-90% (Non Condensing)

24/7/365 Use: Supported

Brightness: 1000nits

CPU: J1900

Resolution: 640*480

Highlight:

all in one panel pc

industrial touch panel pc

Basic Infomation

Place of Origin: China

Brand Name: ITD

Certification: CE, FCC, RoHS

Model Number: ITD06PPCT1HBPJ1

Payment & Shipping Terms

Packaging Details: 1-5pcs/CTN, Safe, Firm

Delivery Time: 15-20 Business Days

Payment Terms: T/T, Western Union, Paypal

Supply Ability: 5000PCS/Month

Gallery

High Definition 6.5 Inch Sunlight Readable Panel PC 4GB Energy Efficient

Product Description

6.5 inch high brightness sunlight readable panel mount industrial touch all in one Panel PC with touchscreen optional

ITD's high brightness panel mount Panel PC's Equipped with powerful Intel Processors, deliver high performance industrial sunlight readable computing with feature rich, low-profile mechanical configurations suitable for harsh environments, and are compliant to NEMA and Ingress Protection standards for front panel.

BENEFITES

- 6.5" Very Bright Active Matrix Sunlight Readable TFT Display; 1000 nits (cd/m2)

- High-Luminance Solid-State LED-enhanced Backlighting

- Intel Celeron 2 GHz Quad Core Processor

- 4GB, Max.8G System Memory

- NEMA 4 (IP65) - Black Powder Coat Aluminum Front Bezel

- Energy Efficient, Low Power Consumption

- High Environmental Performance and Reliability

- Wide Operational Temperature Range, -10°C to +60°C

High Brightness Panel Mount Panel PC
Model Name		ITD06PPCG1HB**
IP Rating		IP65 Front Panel
PC Systems Options
ARM Android Based RK3288(RK3368 optional)	X86 Windows Based		X86 Windows Based
CPU: Quad-Core Cortex-A17 1.8GHz	CPU: Intel® Celeron J1900		CPU: Intel Core i3/i5/i7
Chipset: N/A	Chipset: Intel® HD Graphics, Support 1080p		Chipset: Intel® HD Graphics, Support 1080p
Memory: 1G/2G	Memory: 2GB(Max. 8GB)		Memory: 2GB(Max. 8GB)
HDD/SSD: 8G	HDD/SSD:500G/64G		HDD/SSD:500G/64G
1×HDMI	1×VGA, 1×HDMI		1×VGA, 1×HDMI
1×USB 2.0	2×USB 2.0, 2×USB3.0		2×USB 2.0, 2×USB3.0
1×mini-SD slot	1×COM(RS232/422/485)		1×COM(RS232/422/485)
1×LAN	1×LAN		1×LAN
1×Audio Out	1×Audio Out, 1×MIC In		1×Audio Out, 1×MIC In
Expansion: SSD	Expansion: USB, COM, Mini-PCIe		Expansion: USB, COM, Mini-PCIe
LCD Panel
Screen Diagonal (Inch/cm)		7”
Display Active Screen Size (mm)		132.48(H)X99.36(V)
Aspect Ratio		4:3
Physical Resolution640		640X480
Maximum Resolution Supported		1920X1080
Colors		16.7M
Brightness (cd/m²)		1000(1500 Optional)
Contrast Ratio		500:1
View Angels		70/70/60/60
Backlight/Backlight Lifetime		LED Backlight with 50000 Hours’ Lifetime
Touch Panel
Touch Options		Resistive, IR, PCAP, SAW
Touch Drivers		Windows, Linux, Android, Mac, Raspberry Pi
Operation
Operating Temperature Range		-10~60°C (-20~70°C Optional)
Humidity Range (RH)		10-90%
24/7/365 Use		Supported
Power
Power Indicator		Green LED
Power Input		DC 12V
Power Consumption		20W
Order Information
6.5”1000nits Panel Mount Panel PC with Resistive Touch, J1900		ITD06PPCT1HBJ1
6.5”1000nits Panel Mount Panel PC with PCAP Touch, J1900		ITD06PPCT5HBJ1
6.5”1000nits Panel Mount Panel PC with IR Touch, J1900		ITD06PPCT2HBJ1
6.5”1000nits Panel Mount Panel PC with Tempered Glass, J1900		ITD06PPCG1HBJ1
6.5”1000nits Panel Mount Panel PC with Resistive Touch, i5		ITD06PPCT1HBI5
6.5”1000nits Panel Mount Panel PC with PCAP Touch, i5		ITD06PPCT5HBI5
6.5”1000nits Panel Mount Panel PC with IR Touch, i5		ITD06PPCT2HBI5
6.5”1000nits Panel Mount Panel PC with Tempered Glass, i5		ITD06PPCG1HBI5

APPLICATION
High Definition 6.5 Inch Sunlight Readable Panel PC 4GB Energy Efficient 0

OUR FACTORY
High Definition 6.5 Inch Sunlight Readable Panel PC 4GB Energy Efficient 1
