32" Industrie PC Touchscreen Ip65 Touch Panel Computer With LED Backlight

1pcs

MOQ

TBA

Price

32" Industrie PC Touchscreen Ip65 Touch Panel Computer With LED Backlight

Features Gallery Product Description Request A Quote

Features

Specifications

CPU: Intel J1900/i3/i5/i7/Android

Active Are: 698.4(H)×392.9(V) Mm

Screen Diagonal: 32"

24/7/365 Use: Supported

Touchscreen: PCAP,IR

Power Input: Internal Power Supply, AC 100V~240V

Resolution: 1920X1080

View Angels: 89/89/89/89

Connector: HDMI/VGA/DVI,USB,RS232,LAN,AUDIO,MIC

Name: Touch Monitor PC

Highlight:

touch display pc

,

touch monitor pc

Basic Infomation

Place of Origin: China

Brand Name: ITD

Certification: CE, FCC, RoHS

Model Number: ITD32PPCT5LJ1

Payment & Shipping Terms

Packaging Details: 1-5pcs/CTN, Safe, Firm

Delivery Time: 5-15 Business Days

Payment Terms: T/T, Western Union, Paypal

Supply Ability: 10000PCS/Month

Gallery

32" Industrie PC Touchscreen Ip65 Touch Panel Computer With LED Backlight

Product Description

32" Industrie PC Touchscreen Ip65 Touch Panel Computer With LED Backlight

Specifications:

Chassis Panel PC
Model Name		ITD32PPCG1L**
IP Rating		IP65 Front Panel Optional
PC Systems Options
ARM Android Based RK3288(RK3368 optional)	X86 Windows Based		X86 Windows Based
CPU: Quad-Core Cortex-A17 1.8GHz	CPU: Intel® Celeron J1900		CPU: Intel Core i3/i5/i7
Chipset: N/A	Chipset: Intel® NM10 Express		Chipset: Intel® HD Graphics, Support 1080p
Memory: 1G/2G	Memory: 2GB(Max. 8GB)		Memory: 2GB(Max. 8GB)
HDD/SSD: 8G	HDD/SSD:500G/64G		HDD/SSD:500G/64G
1×HDMI	1×VGA, 1×HDMI		1×VGA, 1×HDMI
1×USB 2.0	2×USB 2.0, 2×USB3.0		2×USB 2.0, 2×USB3.0
1×mini-SD slot	1×COM(RS232/422/485)		1×COM(RS232/422/485)
1×LAN	1×LAN		1×LAN
1×Audio Out	1×Audio Out, 1×MIC In		1×Audio Out, 1×MIC In
Expansion: SSD	Expansion: USB, COM, Mini-PCIe		Expansion: USB, COM, Mini-PCIe
LCD Panel
Screen Diagonal (Inch)		32”
Display Active Screen Size (cm)		698.4(H)×392.9(V)
Aspect Ratio		16:9
Physical Resolution		1920×1080
Maximum Resolution Supported		1920×1080
Colors		16.7M
Brightness (cd/m²)		400
Contrast Ratio		1200:1
View Angels		89/89/89/89
Backlight/Backlight Lifetime		LED Backlight with 50000Hours'Lifetime
Touch Panel
Touch Options		Resistive, IR, PCAP, SAW
Touch Drivers		Windows, Linux, Android, Mac, Raspberry Pi
Operation
Operating Temperature Range		0~50°C (-10~60°C Optional)
Humidity Range (RH)		10-90%
24/7/365 Use		Supported
Power
Power Indicator		Green LED
Power Input		Internal Power Supply, AC 100V~240V
Power Consumption		83W
Order Information
32”Chassis Panel PC with Resistive Touch, J1900		ITD32PPCT1LJ1
32”Chassis Panel PC with PCAP Touch, J1900		ITD32PPCT5LJ1
32”Chassis Panel PC with IR Touch, J1900		ITD32PPCT2LJ1
32”Chassis Panel PC with Tempered Glass, J1900		ITD32PPCG1LJ1
32”Chassis Panel PC with Resistive Touch, i5		ITD32PPCT1LI5
32”Chassis Panel PC with PCAP Touch, i5		ITD32PPCT5LI5
32”Chassis Panel PC with IR Touch, i5		ITD32PPCT2LJ1
32”Chassis Panel PC with Tempered Glass, i5		ITD32PPCG1LI5

ITD industrial touch panel PC-based HMIs offers many benefits including: cost reduction, a lightweight frame, high dimensional stability, superior corrosion resistance, improved mechanical properties, high thermal and electrical conductivity, and the ability to retain strength at high temperatures.

32" Industrie PC Touchscreen Ip65 Touch Panel Computer With LED Backlight 0

OUR FACTORY

32" Industrie PC Touchscreen Ip65 Touch Panel Computer With LED Backlight 2
